Version: 1.9.10

Setting up a deployment

Many users will want to manage multiple code locations within a single coherent directory structure. dg facilitates this with the concept of a deployment directory.

A deployment directory contains a root pyproject.toml containing deployment-level settings and a code_locations directory containing one or more code locations. A deployment does not define a Python environment by default. Instead, Python environments are defined per code location.

To scaffold a new deployment, run:

dg deployment scaffold my-deployment

Creating a Dagster deployment at my-deployment.
Scaffolded files for Dagster project in my-deployment.

This will create a new directory my-deployment. Let's look at the structure:

cd my-deployment && tree

.
├── code_locations
└── pyproject.toml

2 directories, 1 file

Importantly, the pyproject.toml file contains an is_deployment setting marking this directory as a deployment:

my-deployment/pyproject.toml

[tool.dg]
is_deployment = true

To add a code location to the deployment, run:

dg code-location scaffold code-location-1

Creating a Dagster code location at /.../my-deployment/code_locations/code-location-1.
Scaffolded files for Dagster project in /.../my-deployment/code_locations/code-location-1.
...

This will create a new directory code-location-1 within the code_locations. It will also setup a new uv-managed Python environment for the code location. Let's have a look:

tree

.
├── code_locations
│   └── code-location-1
│       ├── code_location_1
│       │   ├── lib
│       │   │   └── __init__.py
│       │   ├── components
│       │   ├── definitions.py
│       │   └── __init__.py
│       ├── code_location_1_tests
│       │   └── __init__.py
│       ├── uv.lock
│       └── pyproject.toml
└── pyproject.toml

...

note

code-location-1 also contains a virtual environment directory .venv that is not shown above. This environment is managed by uv and its contents are specified in the uv.lock file.

The code-location-1 directory contains a pyproject.toml file that defines it as a code location and component library:

my-deployment/code_locations/code-location-1/pyproject.toml
...
[tool.dagster]
module_name = "code_location_1.definitions"
code_location_name = "code-location-1"

[tool.dg]
is_code_location = true
is_component_lib = true
...

Let's enter this directory and search for registered component types:

cd code_locations/code-location-1 && dg component-type list

┏━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┳━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┓
┃ Component Type                                        ┃ Summary                        ┃
┡━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━╇━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┩
│ dagster_components.definitions                        │ Wraps an arbitrary set of      │
│                                                       │ Dagster definitions.           │
│ dagster_components.pipes_subprocess_script_collection │ Assets that wrap Python        │
│                                                       │ scripts executed with          │
│                                                       │ Dagster's                      │
│                                                       │ PipesSubprocessClient.         │
└───────────────────────────────────────────────────────┴────────────────────────────────┘

This is the default set of component types available in every new code location. We can add to it by installing dagster-components[sling]:

uv add 'dagster-components[sling]'

And now we have a new available component:

dg component-type list

┏━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┳━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┓
┃ Component Type                                        ┃ Summary                        ┃
┡━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━╇━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┩
│ dagster_components.definitions                        │ Wraps an arbitrary set of      │
│                                                       │ Dagster definitions.           │
│ dagster_components.pipes_subprocess_script_collection │ Assets that wrap Python        │
│                                                       │ scripts executed with          │
│                                                       │ Dagster's                      │
│                                                       │ PipesSubprocessClient.         │
│ dagster_components.sling_replication_collection       │ Expose one or more Sling       │
│                                                       │ replications to Dagster as     │
│                                                       │ assets.                        │
└───────────────────────────────────────────────────────┴────────────────────────────────┘

As stated above, environments are scoped per code location. dg commands will only use the environment of code-location-1 when we are inside the code-location-1 directory.

Let's create another code location to demonstrate this:

cd ../.. && dg code-location scaffold code-location-2

Creating a Dagster code location at /.../my-deployment/code_locations/code-location-2.
Scaffolded files for Dagster project in /.../my-deployment/code_locations/code-location-2.
...

Now we have two code locations. We can list them with:

dg code-location list

code-location-1
code-location-2

And finally, let's check the available component types in code-location-2:

cd code_locations/code-location-2 && dg component-type list

┏━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┳━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┓
┃ Component Type                                        ┃ Summary                        ┃
┡━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━╇━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┩
│ dagster_components.definitions                        │ Wraps an arbitrary set of      │
│                                                       │ Dagster definitions.           │
│ dagster_components.pipes_subprocess_script_collection │ Assets that wrap Python        │
│                                                       │ scripts executed with          │
│                                                       │ Dagster's                      │
│                                                       │ PipesSubprocessClient.         │
└───────────────────────────────────────────────────────┴────────────────────────────────┘

As you can see, we are back to only the default list of component types. This is because we are now using the environment of code-location-2, in which we have not installed dagster-components[sling].

For a final step, let's load up our two code locations with dagster dev. We'll need a workspace.yaml to do this. Create a new file workspace.yaml in the my-deployment directory:

my-deployment/workspace.yaml
load_from:
  - python_file:
      relative_path: code_locations/code-location-1/code_location_1/definitions.py
      location_name: code_location_1
      executable_path: code_locations/code-location-1/.venv/bin/python
  - python_file:
      relative_path: code_locations/code-location-2/code_location_2/definitions.py
      location_name: code_location_2
      executable_path: code_locations/code-location-2/.venv/bin/python

And finally we'll run dagster dev to see your two code locations loaded up in the UI. You may already have dagster installed in the ambient environment, in which case plain dagster dev will work. But in case you don't, we'll run dagster dev using uv, which will pull down and run dagster for you in an isolated environment:

uv tool run --with=dagster-webserver dagster dev

note

dg scaffolding functionality is currently under heavy development. In the future we will construct this workspace.yaml file for you automatically in the course of scaffolding code locations, and provide a dg dev command that handles pulling down dagster for you in the background.
